| 1 |
Pixel Pitch |
4,75 mm |
| 2 |
Pixel Density |
44100 pixels/m² |
| 3 |
LED type |
3 in 1 SMD – Full Color : 1Red, 1Green,1Blue |
| 4 |
Cabinet Material |
Steel |
| 5 |
Cabinet Dimension |
960mm (W) x 800mm (H) x 135mm (D) |
| 6 |
Weight |
55kgs/m² |
| 7 |
Brightness |
2200NIT |
| 8 |
Colour |
68.7 billion |
| 9 |
Brightness adjustment |
256 grades |
| 10 |
Viewing angle |
160° |
| 11 |
Best viewing distance |
4m-250m |
| 12 |
Refresh Rate |
≥ 600 Hz |
| 13 |
Frame rate |
≥ 60 fps |
| 14 |
Video input |
S-video , Composite ,SDI,HDSDI,RGBHV.DVI |
| 15 |
Video system |
VGA mapped/NTSC/PAL |
| 16 |
Communication cable |
CAT-5 DATA CABLE |
| 17 |
Brightness difference between pixel |
≤ 5% |
| 18 |
Brightness difference between PCB |
≤ 3% |
| 19 |
Out-of-control pixel |
≤ 1/10000 |
| 20 |
Continual operating period |
≥ 24hours |
| 21 |
MTBF |
≥ 10,000 hours |
| 22 |
Life span |
≥ 100,000 hours |
| 23 |
Level up degree |
≤ ±1mm |
| 24 |
Assembly precision between PCB |
≤ 1mm |
| 25 |
Max. power consumption |
≤ 1200w/m² |
| 26 |
Adv. power consumption |
≤ 600w/m² |
| 27 |
Color Temperature |
3200K – 9300K flexible |
| 28 |
Input voltage |
AC220V/50Hz ±10% or AC110V/60Hz ±10% |
| 29 |
Operating Environment |
Temperature:-20℃－+60℃ Humidity:10%－90%RH |
| 30 |
Video display function |
Synchronous display kinds of text, graphics, pictures, signs, flashes, and any signal from TV, VCD, DVD, Camera, and scanner and so on, support PAL, NTSC. |
